• WABCO Code: 4801062030
• Calculated Volume (dm³): 5.6182
• Distance between holes: 3.94 in
• Max. operating pressure: 188.5 psi
• Mounting: 2x M12 x 1.5
• Port thread 11: M22 x 1.5 JED – 388-4
• Port thread 12: M22 x 1.5 JED – 388-4
• Port thread 21: M22 x 1.5 JED – 388-4
• Port thread 22: M22 x 1.5 JED – 388-4
• Port thread 3: Integrated Silencer
• Port thread 4: M16 x 1.5 JED – 388-4
• Protection class: IP 6K6K / IP 6K9K
• Rated current: 7 A
• Temperature range: -40°C to +80°C
• Voltage: 24 V
• Size (mm x mm x mm): 227 x 165 x 150 mm
• UPC: 193133317739
• Weight : 3.2 kg
