The WABCO 4410501000 is a genuine ABS Wheel Speed Sensor of premium original quality. It is designed for heavy-duty commercial vehicles and trailers to precisely monitor wheel rotation and transmit vital data to the Electronic Control Unit (ECU), ensuring optimal anti-lock braking system (ABS) performance and maintaining vehicle stability during braking.
Features & Benefits for ABS Wheel Speed Sensor WABCO 4410501000
- Measures changes in suspension height and sends data to the air suspension control system
- Helps adjust ride height automatically for improved load distribution and handling
- Necessary for maintaining proper vehicle clearance and suspension response
- Compatible with electronically controlled air suspension (ECAS) systems used in commercial vehicles
- Replacing a faulty sensor helps restore proper ride height adjustments and suspension performance
Technical Specifications & OE Codes:
WABCO 4410501000
Technical Specifications
| Part Number |
4410501000 (441 050 100 0)
UPC Code: 193133439042 |
| Product Type |
ABS Wheel Speed Sensor |
| Application Range |
ABS systems for commercial vehicles and trailers |
| Temperature Range |
-40°C to +120°C |
| Primary Function |
Measures wheel rotational speed for anti-lock braking control |
OE Codes & Cross References (Replaces)
| Manufacturer / Brand |
Reference Code(s) |
| WABCO / MERITOR WABCO |
4410501000, 441 050 100 0 |
| FREIGHTLINER |
TDA4410501000 |
| MACK |
6300-4410501000 |
| VOLVO |
WAB4410501000 |
Technical Data:
• Application: TEBS E
• Calculated Volume: 0.8448 dm³
• Comments: With lever
• Distance between holes: 1.57 in
• Electrical connection: Bayonet DIN 72585-A1-2.1-Sn/K2
• Length: 100 mm
• Mounting: 2x Ø 10.9 mm
• Operational range: ±50°
• Protection class: IP 6K9K
• Rated current: 90 mA
• Temperature range: -40°C to +80°C
• Type: Inductive
• Type of lever: Straight lever
• Voltage: 12 V
• Size 110 x 128 x 60 mm x mm x mm
• UPC: 193133439042
• Weight: 0.126 kg
• Weight: 0.2777 lb
OE Codes:
• ALEXANDER DENNIS: 662172
• DAF: 1365935
• DOLL: 7119045
• FAYMONVILLE: 214004
• FREIGHTLINER: TDAS4410501000
• FUSO (MITSUBISHI): ML220444
• GREAT DANE: 40500160
• GUERRA: 84864
• IRIZAR: 8015544
• KENWORTH: S441-050-100-0
• KODAIRA: VS70000255
• KRONE: 515005712
• KÄSSBOHRER: 21151103152
• KÖGEL: 6503143/0
• KÖGEL: 65031430
• LANGENDORF: 1273177
• LECITRAILER: 4501002
• LEYLAND DAF: ABRA506
• LEYLAND DAF: 1365935
• LOHR: A05101487
• MAC TRAILER: 24900025
• MAC TRAILER: 41002787
• MACK: S4410501000
• MACK: 6300-4410501000
• NIPPON SHARYO: A6000JC15902
• NIPPON TREX: 924301-00114
• NOOTEBOOM: 3478622
• OTOKAR: AIF2063
• PACCAR: 1365935
• PETERBILT: S441-050-100-0
• RENAULT: 5010422344
• RODOFORT: 51462
• SCANIA: 1934584
• SCHMITZ CARGOBULL: 1055349
• SCHWARZMÜLLER: 86461
• TIRSAN: 21151103152
• TOHO: Z3-1800236
• TOHO: B3226-3197-0
• UD TRUCKS: 5437030Z0A
• VDL: 759000181
• VDL: 20262643
• VDL: 262643
• VOLVO: WA4410501000
• VOLVO: WAB4410501000
• WABASH: 10800500
